Manufacturing Facilities

Facility name Capacity Quantity
Chip mounters
YAMAHA YG100B
  • Odd-shaped parts
  • Super tiny chip size: 0402 ～
  • CSP/BGA mountable
 4
Solder paste screen printer
YAMAHA YGP
  • Print precision: ±0.0025 mm
  • Repetitive positional accuracy: ±0.005 mm
 1
Reflow
ANTOM SOLSYS-8310IRTP
  • Far-infrared panel heater method
  • Work piece size: 50 – 310 mm
 2
Cold heat impact device
ESPEC TSA-41L-A
  • Constant temperature and humidity controller
  • -75 to +200 °C
 1
Microfocus X-Ray Television System
SHIMADZU SMX-1000
  • Maximum X-ray output: 90 KV
 1
SurfaceMounter　　　　　　　YAMAHA YSM20R
  • High-Speed Multi (HM) Head：Minimum chip size:0402
  • Boardsize:W55xL100mm,
  • Height 15mm orless
  • CSP/BGA mountable
 2
PCB InspectionSystem　OMRON VT-S530
  • Inspection principle:3D reconstruction through color highlight and phase shift technology
  • Image resolution: 10μm/15μm
  • Supported PCB size(min.): 50(W)×50(D)mm
  • Supported PCB size (max.):
  • Single lane: 510(W)×680(D)mm
 1
YAMAHA YG100B
YAMAHA YG100B
YAMAHA YGP
YAMAHA YGP
ESPEC TSA-41L-A
ESPEC TSA-41L-A
SHIMADZU SMX-1000
SHIMADZU SMX-1000
omron_rms
omron_rms
YAMAHA YGP & ANTOM SOLSYS-8310IRTP
YAMAHA YGP & ANTOM SOLSYS-8310IRTP
YAMAHA YSM20R
YAMAHA YSM20R
OMRON VT-S530
OMRON VT-S530
